In Canadian underground pipeline laying, cable crossing and other projects, the Canadian HDD, as the core equipment for trenchless construction, is coping with complex terrains such as frozen soil and swamps with professional performance. Hengwang Group's HWF135 Canadian HDD, with targeted design, has shown reliable advantages in multiple North American projects.

1. Canadian HDD Adapting to Diverse Terrains

Canada's terrain covers frozen soil, forests, wetlands, etc. Hengwang's Canadian HDD adopts engineering rubber tracks, which are suitable for complex working conditions such as snow and swamps, with strong adaptability . The equipment can move flexibly in dense forest areas, avoiding ecological damage caused by traditional excavation, perfectly meeting Canadian environmental protection requirements, and allowing the Canadian HDD to maintain stable operation in diverse terrains.

2. Power Guarantee in Low-Temperature Environments

Targeting Canada's cold climate, the Canadian HDD is equipped with a Cummins 81kw engine, which has undergone low-temperature strengthening treatment and is equipped with a preheating system, enabling one-button start at -25°C . The engine torque reaches 3200N·m, and the dual-motor driven power head can efficiently penetrate frozen soil layers, ensuring stable power and low fuel consumption of the Canadian HDD during winter construction.

3. Technical Highlights for Efficient Construction

Hengwang's Canadian HDD has a hydraulic system working pressure of 20.5Mpa, a maximum power head speed of 40m/min, and a maximum pull-back force of 135KN . It is standard equipped with φ52×1.8m drill pipes, and can be optionally equipped with φ60×1.8m drill pipes, combined with an automatic loading and unloading device to reduce manual intervention . In the Quebec project, it completed 200 meters of pipeline crossing in a single day, with efficiency improved by 50%, highlighting the efficient advantages of the Canadian HDD.

4. Compliant Design and Durable Performance

The equipment meets Canadian safety standards, with a rotatable operating platform to optimize the field of view, and an intelligent monitoring system for real-time alarm . Key components have undergone low-temperature heat treatment, the hydraulic system uses high-quality seals, and the whole machine weighs 4500kg with a stable structure . The failure rate is low during long-term construction, and maintenance only requires regular replacement of filters, ensuring the durability of the Canadian HDD.

5. Hengwang's Service Support System

Hengwang provides a 24-hour bilingual hotline for the Canadian HDD, with 15-minute remote guidance. When on-site service is needed, North American engineers depart within 24 hours . The local service network covers major engineering areas, ensuring efficient operation of the equipment, eliminating customers' worries, and making the construction of the Canadian HDD more secure.

6. Choose Hengwang Canadian HDD to Advance North American Projects

Canada has a strong demand for underground engineering, and efficient and reliable equipment is the key. Hengwang's Canadian HDD is suitable for diverse terrains, resistant to low temperatures, efficient, and supported by a sound service system. Now leave a message for consultation, inform us of your project area and geological characteristics, and Hengwang will customize an exclusive Canadian HDD solution to make North American underground construction more efficient and worry-free！
